Speed Comparison

Property Structomer® Model-X Structomer® Model Competitor
Horizontal printing
(Approx. 150 layers / 15mm)
22 mins 45 mins ~40 mins*
Print speed in "Z" direction 41 mm/hr
(0.68mm/min)
20 mm/hr
(0.33mm/min)
23 mm/hr
(0.38mm/min)
Total aligner arches/time
(Printer dependent)
9 arches / 22 mins 9 arches / 45 mins 6 arches / 40 mins*

*As advertised
^ All provided data is preliminary from measurements conducted by Structo Pte. Ltd.


Mechanical Properties

Mechanical Property Metric
Tensile Modulus – ISO 527-1:1996 585 – 734 MPa
Tensile Strength – ISO 527-1:1996 27 – 37 MPa
Elongation At Break – ISO 527-1:1996 7 – 18 %
Flexural Modulus – ISO 178:2010 1911 – 2128 MPa
Flexural Strength – ISO 178:2010 48 – 65 MPa
Elongation To Failure - ISO 178:2010 16 – 37 %
Hardness Shore D – ISO 868:2003 85 – 90
Glass Transition Temperature (Tg) 97 °C / 206 °F
Viscosity at 25 °C 200 – 500 mPa·s
